■ Operator Interface of 15 inch color LCD touch screen

■ Enclosed Tissue treatment system with no pollution of gas leakage, to meet requirement of environmental protection.

■ Mode of Sample processing: Sample not move,Reagent move.

■ it can avoid the risk of  power failure of machine, or other mechanical failure.
■ Timing Mode: Finishing time of tissue processing any day in the week can be set

■ Fuction of Protection System of Power Failure.Once main power restored, the previous protocols is automatically resumed and continue to work in order.

■ 10 Set of Programmes stored in the system  and can be set for purpose.

■ Special design of Reagent Station makes the liquid totally back-flow to avoid any mixture and to extend using time of reagent.

■ Patented design of cassette holder makes reagent and samples thoroughly contact with each other,it improves effection of tissue processing and reduce working time.

■ Dual Purpose of processing: one key switch normal processing motion and Rapid processing motion

■ Rapid Processing motion stirred in day time finished in 3 hours,Normal Processing Motion stirred in the evening.
■ Device for Air pressure transfer: Formal air pressure transfer of several solenoid valves replaced by One single mechanical structure replace formal in order to avoid high fault error.
■ Fuction for changing wax automatically:

■ Wax in No.1 Container wash into waste container,then,wax in NO.2 container goes into No.1 Container,then,No.3 goes into No.2,and so on
■ Fuction of over temperature protection occured by accidental heating
■ Fuction for magnetic stirring which shorten time of tissue processing and make good processing effection.

■ Alarm and Screen display when finishing work.
■ Capacity of tissue processing: 300pcs cassette at most.

■ Bottle amount : 12. 1 - 9 for dehydration reagent,  14 - 16 for cleaning agent

■ Nos of Reagent Station: 12

■ Tissue Processing Station: NO.1 to No.9 Station

■ Washing Station: No.14 to No.16 Station
■ Nos of Wax Tank: 3(No.10,12 and 13)
■ Nos of Working Station: 1

■ Capacity of Processing Station: 9Liters

■ Capacity of Reagent Station ：6L

■ Temp.of Processing Station:

■ Medium is the solvent: ≤45℃

■ Medium is the Wax: 58℃-70℃

■ Operation pressure:＜0.1Mpa
■ Wax temperature :58℃-70℃

■ Wax melt time not more than 3 hours
■ Power input:＜1500VA+10%

■ Time for immerse: 0 - 99 hours 59 minutes
■ Working Voltage:220VAC±10%,50/60HZ
■ Time for Inflow Liquid: no more than 5Min

■ Time for Exclude Liquid: no more than 5Min
■ Stirring time:  set randomly

■ Interval time for Stirring: set randomly
■ Operation mode: manual and automatic

■ Paraffin temperature - adjustable in the range of 55°C-80°C

■ Temperature of reagents up to 0°C-45°C
