KD-TS3D1 Automated Tissue Processor
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
(With intelligent touch screen)
Imported high-quality parts, smooth operation, low noise, ergonomic design
Integrated high-quality LCD screen with intuitive bilingual (Chinese/English) software offers a clear display and simple operation; window-scrolling/flipping human-machine conversation interface provides clear instructions for each step (online help)
Fully intelligent design, enabling timely determination and automatic recovery from an abnormal event
Real-time visual simulation with icons displays working status dynamically, clearly and intuitively
Green inner-cycling air purification system to efficiently adsorb and remove poisonous gas; well-sealed gas-effluxion mechanism to effectively improve the operational environment, environmentally-friendly and safe
This system can be automatically started at any time as programmed
Processing duration is automatically calculated and displayed on the screen, allowing user to make a more efficient work plan
20 editable programs can be stored in the system
Manual adjustment can be conducted anytime during the programmed automatic operation; afterwards, the system automatically enters the programmed operation
Automated fan control: Stays ‘on’ all the time when the specimens are not submerged in cup and 10 seconds every minute when the specimens are submerged in cup and processing
Automated light control:
stays ‘on’ all the time during programming;
stays ‘off’ during the automatic operation and can be automatically turned ‘on’ anytime by touching the screen or any key and stays ‘on’ for 2 minutes.
Internal dry heating mechanism with high-precision temperature control
Automatically determines the time of heating for energy efficiency
Low-energy-consuming control circuit with power protection function
When a power outage occurs, the screen displays as normal with a scrolling bar demonstrating the ‘on’ status of the power protection system
Battery backup with more than 30 hours of running power
Approximately 130 tissue samples can be processed at the same time
Integrated high-quality LCD screen with intuitive bilingual (Chinese/English) software offers a clear display and simple operation; window-scrolling/flipping human-machine conversation interface provides clear instructions for each step (online help)
Fully intelligent design, enabling timely determination and automatic recovery from an abnormal event
Real-time visual simulation with icons displays working status dynamically, clearly and intuitively
Green inner-cycling air purification system to efficiently adsorb and remove poisonous gas; well-sealed gas-effluxion mechanism to effectively improve the operational environment, environmentally-friendly and safe
This system can be automatically started at any time as programmed
Processing duration is automatically calculated and displayed on the screen, allowing user to make a more efficient work plan
20 editable programs can be stored in the system
Manual adjustment can be conducted anytime during the programmed automatic operation; afterwards, the system automatically enters the programmed operation
Automated fan control: Stays ‘on’ all the time when the specimens are not submerged in cup and 10 seconds every minute when the specimens are submerged in cup and processing
Automated light control:
stays ‘on’ all the time during programming;
stays ‘off’ during the automatic operation and can be automatically turned ‘on’ anytime by touching the screen or any key and stays ‘on’ for 2 minutes.
Internal dry heating mechanism with high-precision temperature control
Automatically determines the time of heating for energy efficiency
Low-energy-consuming control circuit with power protection function
When a power outage occurs, the screen displays as normal with a scrolling bar demonstrating the ‘on’ status of the power protection system
Battery backup with more than 30 hours of running power
Approximately 130 tissue samples can be processed at the same time
Technical Specifications
Number of Cups: 12 (The 1st to 9th stations for reagents and the 10th to 12th stations for paraffin melting)
Capacity of Each Cup: 2000 ml
Temperature Range: RT - 80℃
Temperature Control Precision: ±1℃
Length of Processing Time in the Cup:
Any length for the first cup (Extended Time)
Any length between 0 and 24 hours for the 2nd to 12th cup
Dripping Time: Adjustable between 10s and 60s; shake/drip function above cup
Frequency of Agitation: Adjustable within 0 - 6 times/minute
Tissue Protection Station: any station from the 1st to 7th station as preset
Working Voltage: AC220V±10% 50Hz (standard model)AC110V±10% 60Hz
Power: 500 W
Dimensions: 1170×440×540mm (W×D×H)
Net weight: 85kg
Capacity of Each Cup: 2000 ml
Temperature Range: RT - 80℃
Temperature Control Precision: ±1℃
Length of Processing Time in the Cup:
Any length for the first cup (Extended Time)
Any length between 0 and 24 hours for the 2nd to 12th cup
Dripping Time: Adjustable between 10s and 60s; shake/drip function above cup
Frequency of Agitation: Adjustable within 0 - 6 times/minute
Tissue Protection Station: any station from the 1st to 7th station as preset
Working Voltage: AC220V±10% 50Hz (standard model)AC110V±10% 60Hz
Power: 500 W
Dimensions: 1170×440×540mm (W×D×H)
Net weight: 85kg
