KD-2268 Microtome
_pixian_ai.png)
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Features
The Microtome KD-2268 is designed to meet multiple requirements of histology or histopathology labs. It is also suitable for the use in research labs as well as industrial quality assurance. In being manual, the Microtome KD-2268 is flexible to use at any place in the laboratory. With its high-precision mechanics inside, the Microtome KD-2268 permits quality sections, while maintaining a high, consistent throughput. Great functionality and the appealing design are the key features of our microtome. Optimal user comfort enables a rapid, safe and smooth sectioning, even under heavy workload. The integrated sectioning waste tray is resistant to xylene, and can be detached for cleaning.
Technical Specifications
Section Thickness Setting Range: 0–60μm
Section thickness settingoptions:
0–20μm increment 1μm
20–60μm increment 5μm
Trimming Thickness Setting Range: 0- 60μm
Minimum Setting of Sectioning Thickness: 0.5μm
Maximum Specimen Size: 70×70mm
Trimming Thickness: 15μmand 35μm
Specimen Retraction: 60μm(optional)
Total Horizontal Specimen Feed:28mm;
Vertical Specimen Stroke:70mm
Movement Range of the Base of BladeHolder Base: 0-70mm (front to back)
Movement Range of the Blade Press plate: 0-23mm
Specimen Holder Rotation: at any angle within360 degrees
Specimen Orientation:XY – 8°
Precision Error: ±5％
Dimensions: 590×500×330mm (W×D×H)
Net weight: 38kg
Section thickness settingoptions:
0–20μm increment 1μm
20–60μm increment 5μm
Trimming Thickness Setting Range: 0- 60μm
Minimum Setting of Sectioning Thickness: 0.5μm
Maximum Specimen Size: 70×70mm
Trimming Thickness: 15μmand 35μm
Specimen Retraction: 60μm(optional)
Total Horizontal Specimen Feed:28mm;
Vertical Specimen Stroke:70mm
Movement Range of the Base of BladeHolder Base: 0-70mm (front to back)
Movement Range of the Blade Press plate: 0-23mm
Specimen Holder Rotation: at any angle within360 degrees
Specimen Orientation:XY – 8°
Precision Error: ±5％
Dimensions: 590×500×330mm (W×D×H)
Net weight: 38kg
